Makerfire UTMSYS USL40 4G communication link
USL40 4G Communication Link for Drones – Beyond Line-of-Sight Control, HD Image Transmission & Data Backhaul
The USL40 4G Communication Link is a specialized communication module designed for drones, providing beyond-line-of-sight (BLOS) control, high-definition image transmission, and data backhaul over a 4G LTE network. This module helps drones overcome the limitations of traditional line-of-sight communication, enabling seamless control and data transfer over long distances and in complex environments.
With its ability to support network RTK (Real-Time Kinematic) integration, the USL40 ensures high-precision positioning, making it a crucial component for applications in industries like surveying, mapping, and inspection. It also offers communication link redundancy to improve operational reliability, ensuring that drones can function safely and efficiently in a wide range of environments.
Whether for industrial, agricultural, or research purposes, the USL40 4G Communication Link enhances the operational capabilities of drones by enabling real-time control, telemetry, and high-quality image transmission at extended ranges.
Key Features:
- Beyond-line-of-sight control for extended range operations
- HD image transmission and data backhaul for real-time data transfer
- Integration with network RTK for high-precision positioning
- Redundant communication link for reliable and safe operation
- Compact and lightweight design for easy integration into drones
- No voice calls or SMS support – Focused on data and telemetry
Technical Specifications:
- Working Voltage: 12V
- Instantaneous Current: 1A
- Transmission Rate: 300Kbps
- Supported Standards: FDD-LTE
- Support for TCP/IP: TCP
- Voice Calls Support: No
- SMS Support: No
- Phone Book Support: No
- Size: 59mm x 41mm x 16mm
- Weight: 47g
- Power Consumption: 1.5W
- Operating Temperature: -20°C to 60°C
Interfaces:
- Voltage Input: XT30
- WAN Interface: MX1.25-4P
- LAN Interface: MX1.25-4P
- UART Interface: MX1.25-4P
- SIM Card Slot: Nano SIM
- Antenna Plug: MMCX *2
- Indicator Light: 4
Description
